Core Functions & Specifications

• AC-DC-AC Power Conversion:

• Input/Output Parameters: Accepts 3-phase AC input (380V–480V AC, 50/60Hz; optional 200V–240V AC for low-voltage setups) and converts it to stable DC power via a 6-pulse rectifier (DC link voltage: 540V–670V). Inverts DC power to variable-frequency 3-phase AC output (0–500Hz) for motor control, supporting both V/f control (simple loads like fans) and vector control (precise torque applications like compressors).

• Efficiency & Power Density: Delivers a maximum efficiency of 98% (at 75% load) and features a compact design (210mm × 320mm × 125mm typical)—saving 30% of cabinet space vs. legacy mid-range modules and reducing heat generation, which lowers the need for additional cooling systems in control panels.

• Sinamics G220 Compatibility & Integration:

• Drive-Specific Matching: Designed exclusively for Sinamics G220 inverters, connecting seamlessly to G220 Control Units (e.g., CU250D-2 PN) via Siemens’ proprietary backplane bus. Supports "auto-parameterization"—automatically detects the control unit and loads optimized settings (e.g., motor rated current, speed range, torque limits), eliminating manual configuration and cutting setup time by 72%.

• Dynamic Load Handling: Integrates Siemens’ "Adaptive Torque Management" to handle sudden load spikes (150% rated torque for 60 seconds, critical for conveyor jam recovery or compressor startup) and "Smart Energy Optimizer" to adjust switching frequency (2kHz–16kHz) based on load. For example, it reduces switching losses by 32% when a pump operates at 40% capacity, directly lowering energy use.

• Protection & Safety Features:

• Multi-Layer Fault Shielding: Equipped with overcurrent protection (trip current: 125% rated current), overvoltage protection (DC link cutoff at 750V), undervoltage protection (DC link cutoff at 350V), and overtemperature protection (shutdown at 85°C module temperature). Includes input (line-to-line) and output (motor terminal) short-circuit protection to prevent module burnout and motor damage from electrical faults.

• Safety Compliance: Integrates "Safe Torque Off" (STO) function meeting SIL 2/PL d safety standards—cuts motor torque without disconnecting main power, enabling safe maintenance (e.g., pump impeller inspections) and avoiding unintended startup in high-traffic industrial areas (e.g., factory floors with frequent worker access).
