PROFINET Side:
→ Operates as IO Controller (managing remote I/O, drives) or IO Device (connecting to PLCs like Siemens S7-1500).
→ TSN-Ready: Hardware support for IEEE 802.1AS-rev time synchronization.

ControlNet Side:
→ Functions as Adapter (slave to ControlLogix PLCs) or Scanner (master for ControlNet devices like Flex I/O).
→ Native CIP Routing: Transfers Produced/Consumed Tags without data mapping.

Processing Power:
→ 64-bit ARM Cortex-A53 processor (1.2 GHz) for deterministic real-time performance.

Interfaces:
→ PROFINET: 2× Gigabit RJ45 (MRP/DLR redundancy, TSN support).
→ ControlNet: BNC coaxial terminal (5 Mbps, redundant media).

Robust Design:
→ Extended temp. -40°C ~ +85°C (metal housing with active cooling).
→ Dual 24V DC power inputs (redundant, ±20% tolerance).

Zero-Config Routing:
→ SYCON.net automates CIP ↔ PROFINET data bridging (preserves tag structures).

Edge Computing:
→ On-board Linux OS supports custom Python/Java apps (e.g., data pre-processing).

Cyber Security:
→ Hardware-trusted boot, OPC UA over TLS 1.3 encryption.
