Hilscher NT 50-CC-EN-CC ControlNet to Industrial Ethernet Multi-Protocol Gateway

Hilscher NT 50-CC-EN-CC ControlNet to Industrial Ethernet Multi-Protocol Gateway

ControlNet Adapter; ControlNet Scanner; EtherNet/IP Device; PROFINET IO Device; OPC UA Server; Dual RJ45 Gigabit Ports; Coaxial BNC Interface; -40°C ~ +70°C; CIP Protocol Routing; SYCON.net Configuration; Compact Rail Mount

0.00
0.00


ControlNet Adapter; ControlNet Scanner; EtherNet/IP Device; PROFINET IO Device; OPC UA Server; Dual RJ45 Gigabit Ports; Coaxial BNC Interface; -40°C ~ +70°C; CIP Protocol Routing; SYCON.net Configuration; Compact Rail Mount

  1. Dual ControlNet Roles

    • ControlNet Side:
      → Adapter Mode: Connects as a slave to ControlNet scanners (e.g., Rockwell ControlLogix PLCs).
      → Scanner Mode: Actively manages ControlNet devices (e.g., Flex I/O, drives).

    • Industrial Ethernet Side:
      → EtherNet/IP Device: Seamless integration with Rockwell Studio 5000 systems.
      → PROFINET IO Device (optional): Compatible with Siemens TIA Portal.
      → OPC UA Server (license required): Secure cloud data transmission.

  2. Compact Hardware Design

    FeatureSpecification
    ControlNet InterfaceBNC coaxial terminal (5Mbps, redundant media support)
    Ethernet Interface2× Gigabit RJ45 (DLR ring redundancy)
    Mechanical DesignUltra-compact aluminum housing (35mm width)
    Power Supply24V DC (±10%), ≤4W power consumption
    Environmental Rating-40°C ~ +70°C, 5g vibration resistance

  3. Intelligent Protocol Routing

    • CIP Data Bridging:
      → Native CIP protocol routing between ControlNet and EtherNet/IP (no data mapping required).
      → Supports cross-segment Produced/Consumed Tags transfer.

    • Multi-Protocol Conversion:
      → Configure ControlNet-to-PROFINET/OPC UA rules via SYCON.net.
      → Generate EDS files (ControlNet) and GSDML files (PROFINET).

  4. Engineering & Diagnostics

    • Zero-Code Integration:
      → Pre-certified for ODVA ControlNet & EtherNet/IP.
      → Directly import EDS files into Studio 5000.

    • Dual-Layer Diagnostics:
      → Physical Layer: LED indicators for ControlNet media status (green: normal, red: conflict).
      → Protocol Layer: Web server for real-time traffic monitoring (CIP packet statistics).
