Overview
The ABB PFEA113-20 is a advanced communication interface module that enables seamless integration of AC 800M controllers with PROFINET IO networks. This module facilitates real-time data exchange between the controller and various PROFINET IO devices, ensuring precise control and monitoring in industrial automation environments. The module is certified for PROFINET Conformance Class B, providing enhanced diagnostics and network management capabilities.

Key Features & Benefits:

• PROFINET IO Communication: Provides real-time communication with PROFINET IO networks, supporting cycle times up to 1 ms

• Conformance Class B: Meets PROFINET Conformance Class B requirements for enhanced diagnostics and network management

• Dual-Port Switch: Integrated 2-port switch enables linear network topology without additional hardware

• High Availability: Support for MRP (Media Redundancy Protocol) for network redundancy

• Diagnostic Capabilities: Comprehensive network diagnostics and device monitoring for enhanced system maintenance

• Easy Configuration: Simple setup and configuration through ABB's Control Builder engineering tool

Technical Specifications:

• Product Code: PFEA113-20

• Order Number: 3BSE050092R20

• Interface Type: PROFINET IO

• Standard: IEC 61158/61784, PROFINET IO Conformance Class B

• Ports: 2 x RJ45 (10/100 Mbps) with integrated switch

• Protocol: PROFINET IO, RT and IRT support

• Redundancy: MRP (Media Redundancy Protocol) support

• Compatibility: AC 800M Controller

Typical Applications:

• Factory automation systems

• Process control applications

• Motion control systems

• Manufacturing execution systems

• High-speed automation applications

Compatibility:
The PFEA113-20 module is specifically designed for:

• ABB AC 800M high-performance controllers

• ABB Symphony Plus control systems

• PROFINET IO field devices

Note: For complete technical specifications and configuration guidelines, refer to the official ABB PFEA113 series documentation. Proper configuration requires expertise in PROFINET networks and ABB control systems.
