Overview
The Hitachi Energy 5SHY3545L0020 represents advanced press-pack IGBT technology, delivering superior performance in high-power electronic systems. This dual IGBT module is engineered for applications requiring maximum reliability, power density, and thermal cycling capability.

Key Features & Benefits:

• Press-Pack Technology: Provides direct cooling through both sides of the semiconductor, enabling low thermal resistance and superior reliability under thermal cycling conditions

• Dual IGBT Configuration: Integrates two IGBTs in a single module, optimizing power density and simplifying converter design

• Short-Circuit Ruggedness: Exhibits excellent short-circuit withstand capability, enhancing system reliability

• Low Stray Inductance: Optimized internal design minimizes parasitic inductance for improved switching performance

• High Power Density: Enables compact converter designs while maintaining high power handling capability

Technical Specifications:

• Product Code: 5SHY3545L0020

• Order Number: 3BHE014105R0001

• Technology: Press-Pack IGBT

• Configuration: Dual IGBT

• Voltage Rating: Medium voltage level (specific voltage class depends on variant)

• Current Rating: High current capability suitable for power applications

Typical Applications:

• Medium-voltage variable speed drives

• HVDC transmission systems

• Flexible AC transmission systems (FACTS)

• Static VAR compensators (SVC)

• Industrial power supplies

Compatibility:
This module is compatible with Hitachi Energy's power electronic systems and can be integrated into various converter topologies.

Note: For complete technical specifications, application guidelines, and handling procedures, please refer to the official Hitachi Energy product documentation. Proper handling requires expertise in high-power electronics.
