The ProSoft Technology MVI69-PDPS is a specialized communication module designed to integrate Allen-Bradley ControlLogix programmable controllers into Profibus DP networks as a slave device. This module solves critical interoperability challenges by allowing ControlLogix systems to exchange data with Profibus DP master devices (such as Siemens PLCs or DCS systems) without requiring custom programming or additional hardware.

Key Technical Features:

• Profibus DP Slave Protocol: Complies with Profibus DP-V0/V1 standards, supporting cyclic and acyclic data exchange.

• High-Speed Data Transfer: Supports baud rates up to 12 Mbps, ensuring efficient real-time communication.

• Flexible Data Mapping: Configurable input/output data mapping between Profibus DP and ControlLogix tags.

• Diagnostic Capabilities: Provides detailed module and network diagnostics for easy troubleshooting.

• Hot-Swappable Design: Supports hot swapping in ControlLogix chassis for minimal downtime.

Technical Specifications:

• Compatibility: Allen-Bradley ControlLogix (1756 chassis)

• Profibus DP Standards: EN 50170, IEC 61158/61784

• Data Rates: 9.6 kbps to 12 Mbps (auto-negotiation)

• I/O Data Size: Up to 244 bytes input/output

• Power Consumption: 1.8A @ 5V DC (from backplane)

• Isolation: 1500V AC (network to backplane)

Typical Applications:

• Integrating ControlLogix systems into Siemens-based Profibus DP networks.

• Connecting legacy Profibus DP equipment to modern ControlLogix-controlled machinery.

• Enabling data exchange between Process Control Systems (DCS) and discrete ControlLogix controllers.

The MVI69-PDPS exemplifies ProSoft’s expertise in bridging industrial protocols, providing a reliable solution for multi-vendor automation environments while reducing integration complexity and costs.
