The GE 605-108114-003 is a high-performance DC digital input module engineered for industrial automation and control systems. This module serves as a critical interface between field devices and control systems, accurately acquiring digital signals from sensors, switches, and other DC field devices.

Key Technical Features:

• High-Density Inputs: Supports multiple DC digital input channels in a compact module design

• Wide Voltage Range: Compatible with various DC voltage levels (e.g., 24VDC, 48VDC)

• Fast Response Time: Rapid signal processing for real-time control applications

• Noise Immunity: Advanced filtering and isolation techniques ensure reliable operation in electrically noisy environments

• Diagnostic Capabilities: Built-in status indicators and diagnostic functions for easy maintenance

Technical Specifications:

• Input Channels: 16 channels (typical configuration)

• Input Voltage: 24VDC nominal (range: 19-30VDC)

• Input Current: 3-5mA per point

• Response Time: < 10ms

• Isolation: 1500VAC channel-to-channel and channel-to-ground

• Operating Temperature: -20°C to +60°C

• Connection Type: Removable terminal block

• Compatibility: Designed for GE control platforms

Typical Applications:

• Discrete manufacturing automation

• Process control systems

• Material handling equipment

• Machine tool controls

• Power generation auxiliary systems

The 605-108114-003 module exemplifies GE's commitment to industrial automation excellence, providing reliable digital signal acquisition for critical control applications across various industries.
