Key Functions

• Multi-Protocol Industrial Communication:
  Natively supports mainstream industrial communication protocols to adapt to varied automation architectures, including:

• Profinet IRT: Enables high-speed, deterministic communication (cycle times down to 1ms) for time-sensitive applications (e.g., synchronized motor control in steel processing).

• Modbus TCP/IP: Facilitates long-distance, cost-effective data exchange with SCADA or HMI systems (e.g., remote monitoring of water treatment pumps).

• EtherNet/IP: Ensures compatibility with Rockwell Automation-based control systems, supporting bidirectional data flow for parameter configuration and status feedback.

• Optional protocol customization (via ABB’s Control Builder Plus software) to match site-specific protocol requirements.

• Supplementary Control Logic Execution:
  Provides a built-in programmable logic engine to run customized control sequences, reducing reliance on external PLCs for simple-to-medium complexity tasks:

• Supports ladder logic or function block programming (FBD) for workflows like sequential startup/shutdown of multi-inverter systems, interlock protection (e.g., blocking operation if safety gates are open), or load-sharing between parallel drives.

• Integrates 4x digital I/O channels (2 inputs, 2 outputs) for direct connection to local sensors or actuators, enabling standalone control loops (e.g., temperature-based speed adjustment for fans).

• Real-Time Data Synchronization:
  Transmits inverter operating data (e.g., output voltage, motor torque, fault codes) and receives control commands (e.g., speed references, mode switches) with a maximum data refresh rate of 100Hz, ensuring upper-level systems have up-to-date visibility and responsive control over the inverter.

• Fault Tolerance & Diagnostics:
  Features built-in communication error detection (e.g., packet loss, protocol mismatch) and auto-recovery mechanisms. It logs communication faults and internal module errors, transmitting detailed fault codes to both the inverter’s main display and upper-level systems. Local LED indicators (communication active, fault) provide at-a-glance status for quick troubleshooting.
