Core Functions & Specifications

• Stable Power Regulation:

• Input/Output Parameters: Accepts wide-range AC input (110V–240V AC, 50/60Hz) and converts it to regulated DC output (typical: 24V DC @ 10A or 48V DC @ 5A; exact values depend on drive model). Output voltage ripple ≤50mV (peak-to-peak), ensuring no interference with sensitive drive control circuits (e.g., encoder signal processing).

• Surge & Overload Protection: Integrates a built-in surge protector (up to 6kV) to shield against grid voltage spikes, and a current-limiting function that triggers at 120% of rated output—preventing module burnout and protecting downstream drive components (e.g., IGBT modules).

• Drive-Specific Compatibility:

• Sinamics Series Match: Fully compatible with Siemens Sinamics S120 (single/multi-axis drives) and G120XA (high-performance modular drives), including compatibility with drive frames SI/SI+/SII. It interfaces seamlessly with Sinamics Control Units (e.g., CU320-2 PN) via a dedicated 16-pin connector—no additional wiring or software configuration required (plug-and-play design).

• Signal Feedback: Embeds a status monitoring circuit that transmits real-time power output data (voltage/current) to the drive controller. Triggers visual alarms (via LED indicators) for abnormal conditions (e.g., input voltage loss, output overload) and supports remote fault diagnosis via PROFINET.

• Industrial Environmental Resilience:

• Operating Conditions: Withstands a wide temperature range (-25°C to +70°C) and humidity up to 95% (non-condensing), suitable for harsh sites like mining facilities (dust) and outdoor water treatment plants (moisture).

• Mechanical Protection: Features a rugged aluminum alloy housing (IP20 protection for the module itself; IP54 when installed in a Sinamics drive cabinet) and anti-vibration design (resistant to 50Hz mechanical vibration up to 2g), ensuring long-term stability in high-vibration equipment (e.g., industrial mixers).
