Core Functions & Specifications

• Auxiliary Control Module Mode:

• Signal Processing: Converts 4-20mA analog sensor signals (e.g., inverter cabinet temperature) to digital data, with a transmission accuracy of ±0.3% and delay ≤15ms, ensuring real-time status feedback to the inverter controller.

• Fault Alarming: Triggers active alarms for abnormal conditions (e.g., over-temperature, signal loss) via dry contact output, supporting integration with DCS/PLC systems for centralized monitoring.

• Filter Element Mode:

• Filtration Efficiency: Made of gradient-density polyester fiber, it captures ≥98% of particles ≥3μm (dust, oil mist) in the inverter’s forced-air cooling system, with a service life of 4–6 months under standard industrial conditions (35°C, 55% humidity).

• Installation Design: Features a self-sealing frame to prevent bypass leakage, compatible with Robicon G5/G6 inverter cooling air inlets (size: 180×120×25mm).

• Universal Compatibility: Works seamlessly with Siemens Robicon G5 (e.g., matching power unit A5E42740246) and G6 series inverters, requiring no hardware modification or software reconfiguration during replacement.

Application Scenarios

• Power Plant Boiler Drives: Used as a filter element in Robicon inverters for induced draft fans, blocking fly ash from entering the cooling system and reducing inverter overheating faults by 60%.

• Steel Mill Rolling Mills: Functions as a control module to monitor inverter output current, adjusting signal gain in real time to avoid motor overload caused by fluctuating rolling loads.

• Petrochemical Refineries: Serves as a dual-purpose spare part for compressor inverters—filters prevent oil vapor contamination, while the control module monitors ambient temperature to adjust cooling fan speed.

Reliability & Compliance

• Environmental Durability: The control module operates in -25°C to +75°C (IP20 protection); the filter element resists moisture and chemical corrosion (compatible with industrial cleaning agents), adapting to harsh sites like coastal power plants.

• Certifications: Meets IEC 61800-3 (EMC for drives) and ISO 14644-1 (cleanroom standards for filters), complying with global industrial safety regulations.

• Maintenance Convenience: The filter element has a visual contamination indicator; the control module supports online status checking via Robicon inverter HMI, simplifying maintenance planning.
